I was doing a bit of troubleshooting today at work. A customer has a bus that won't crank over.



Anyway, if you think modern car electrics are mental, get ready for this one:



Instead of a switch attached to a wire going to the starter solenoid:







Because I could never get to the bottom of the random starter-not-working on my, my wifes, now mine again, Subaru Legacy



I fitted a metre of wire and a push-button.



Up yours immobiliser/relays/can-bus/engine management module/body control module.

[Inspector Morose]

I was doing a bit of troubleshooting today at work. A customer has a bus that won't crank over.



Anyway, if you think modern car electrics are mental, get ready for this one:



Instead of a switch attached to a wire going to the starter solenoid:





The start button sends a physical (negative switched) pulse to an Input/Output unit (one of 5 or 6 identical ones on the bus). This encodes the signal into a data packet, which then travels over the Multibus network to the CAMU - the master on this particular network. If the CAMU is happy that the battery level isn't too low and the engine bay door is shut etc, it sends another data packet out to the dash clocks.

The dash clocks are a bridge between the Multibus "buttons and doors and lights" network to the proper J1939 network which is for the oily mechanical bits.

Anyway, this vehicle has a Mercedes engine, so instead of the engine ECU being on this network, it's got an ADM unit which is like the Mercedes "gateway" to the ECU at the front of the vehicle which picks up the signal from the throttle pedal and ignition and stuff.

So, this ADM receives a packet from the dashboard saying "start the engine". If it's happy with various things (oil level and stuff) then it'll send another data packet out on ANOTHER network - fault tolerant CAN this time. (It runs at higher voltage than normal CAN)

This data finally travels down some wires to the back of the bus and into the engine ECU where it's decoded back into a physical pulse, which then passes through for transistors in series with a current sensing resistor before finally making it's way to the starter solenoid.



I can't really believe this is the first time I've been asked for help with this.

The ECU does have a pin marked "Terminal 50, Starter in" but if you start it using that, the vehicle just runs at 1250RPM in limp mode and ignores the throttle pedal.

Optare product per chance?

[cobblers]

Cobblers, that is insane, I'm sure whoever came up with that convoluted load of bollocks thought to ask the poor sods who operate/maintain them if they thought it was a good idea.



It's all down to how the systems all were designed totally separately and were forced to work together.



The Merc stuff was originally on trucks and had a wire direct from the ignition to the starter terminal - the rest was "bonus comfort stuff" so it wasn't important for it to be all that robust.

The Actia/optare stuff originally was designed for Cummins engines with a +24v feed for the starter and no intercommunication between the dash and the doors/lights multibus network, so again it didn't need to be all that robust (and it really flipping isn't!)

Then they updated it because the newer euro4/5 merc engines prefer to be started just via the network.





TBH with three quarters of a brain and the diagnostics tackle, it's not that bad to deal with. But you'll need two different types of gear, both at 3-7k subscription per year. Only one of them is available knockoff on ebay for £50.

[cobblers]

Optare product per chance?

Of course! Solo.

I love Solos! They're great. They pay for my car and house.

[scaryoldcortina]

Only one of them is available knockoff on ebay for £50.

Is the other one MBstar/DAS/Xentry?

[cobblers]

I'm told the knockoff Delphi DS150 is good enough for the Merc stuff, We use a genuine one and it does what we need on the test bench.

It's the Actia multibus diagnostics for the body modules that's the real stinger because there's no cheap alternative and there's really no other way to work out whats wrong other than just throwing parts at it.
