Dumb question about XUD engines.

[Lankytim]

Hi shitterZ.



I've got an engine from a 1994 Pug 405 1.9d to go in my 2000 LDV Pilot. both have a 1.9 XUD dizzler engine. Should be a fairly straightforward swap BUT some exhaust/inlet manifold gaskets on ebay for the Pug engine have two big square ports for the exhaust manifold and seemingly the LDV has individual round ports. I haven't actually taken the manifolds off to check yet, the Pug engine has a big round thing attatched to the underneath, if that helps identification.



I guess if the manifolds cant be swapped about then i'll have to swap the heads instead.





Any resident XUD perverts got any info?

[twosmoke300]

Early engines were square port iirc . And the 1.7

[Dave_Q]

Possibly a dumb answer, but the bolt holes and general shape of those gaskets look the same. I would get the gasket that matches the manifold and whack it on anyway?

[jonathan_dyane]

Being 94 the pug should be round port

[dollywobbler]

Agree with the others. Changeover was late 1980s I think.

[Lankytim]

Cheers guys, hopefully they'll be the same and this will simplify the job quite a bit!



Any ideas what the big metal round thing on the bottom of the manifold could be? It's like an expansion chamber or something.

[Richard]

It's some kind of resonator. Can be replaced with a flat plate if required.

[tommotech]

The cylinder head is the same so don't panic.

The euro 2 Pilots, with EGR, used an exhaust manifold from a turbocharged XUD9TE and bolted the down pipe to the triangular flange. This manifold has the lower type gasket, the rectangular type will leak.



Hope this helps.
