Wiring Diagram for Mercdes W124 Head Lights

[Six-cylinder]

Help!



The dip bean and now the main beam instead has stopped working on our 1990 200TE W124.



When I wiggled the replay under the fuses the dip started working, but the main beam has now stopped.



Can somebody point me to a wiring diagram for the headlights please?

[mercrocker]

http://www.mercedesw124.com/mercedes-w124-information/



There is some stuff on here I used to refer to, lots is in Russian but schematics should be helpful...

[Six-cylinder]

http://www.mercedesw124.com/mercedes-w124-information/



There is some stuff on here I used to refer to, lots is in Russian but schematics should be helpful...



I need a bit more detail.



I have now found a 1995 E320 diagram, but is it the same?

[doug]



Hope you can make this out! PM me your address and I will post you down the Haynes manual if you want it.

[richardmorris]

I have this manual with pull out wiring diagrams. Could drop off on Friday if you like- I'm up to the Lake District on holiday. It's not going to work trying to photo it.



https://www.ebay.co.uk/itm/Mercedes-W124-Owners-Workshop-Manual-1985-1995-200-200E-E200-E220-220E/332434778147?epid=88413121&hash=item4d66a82823:g:2~kAAOSwRrlZ-wrO
