405 doesn't want to drive


  • Please log in to reply
12 replies to this topic

#1 OFFLINE   carlo

carlo

    Rank: Renault 16

  • Full Members
  • 2,161 posts
  • 1 thanks
  • LocationPlymouth
  • Country : Country Flag

Posted 15 April 2018 - 05:58 PM

Would be very grateful if anyone has any other advice on trying to get my daily back on the road.



For a month now it won't idle properly; either cuts out as soon as you take your foot off the throttle, or may work sometimes but then cuts out after a few minutes.  You also get a 'surging, engine braking' sensation when driving, although under load it seems fine and accelerates without issue.



I thought I would be able to fix this myself, the last time it did something similar I discovered an air pipe to the MAP sensor was half hanging off; re-connected it and all was A1 again.  This time, despite the same pipe looking a bit loose it made no difference when I secured it.  Have replaced the idle air control valve, checked all pipes for leaks, and even replaced the whole throttle body with another working one to no avail, still cuts out and has added a symptom of rev surging between 800 - 1500 revs too.  I think I may have changed too many bits now and probably gone backwards.  My mechanic is not sure what to do next, suggested I let a garage loose on it.  He's suggested it might be the fuel pump sender unit above the tank starting to fail, well I have a spare so could try that.  Or possibly crank sensor??  He doesn't see to think it's anything to do with plugs/leads as it starts fine and works on all 4 cylinders.



This is the worst issue I've had with it in four years.  Bollox.









  • Nibblet likes this

#2 OFFLINE   BoggyMires

BoggyMires

    Rank: Austin Maxi

  • Full Members
  • 353 posts
  • 8 thanks
  • LocationThe A14
  • Country : Country Flag

Posted 15 April 2018 - 06:17 PM

You got an afm on it? If so, check it's sweeping correctly and within its operating parameters.  8)


1986 BMW 635CSi - Works but doesn't work

1998 BMW E36 318i Touring - Works

2001 Land Rover Discovery V8 - FuBarred


#3 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    He's a right bastard.

  • Full Members
  • 7,673 posts
  • 37 thanks
  • LocationSheffield On Thames.
  • Country : Country Flag

Posted 15 April 2018 - 06:21 PM

Considering how much these are worth now, I'd fire it into a main dealer.



'Fix it my good man'.



:-D


  • warren t claim, The Moog, Magnificent Rustbucket and 4 others like this

MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1994 M 318Ti - Track whore

1998 S 323iA Touring. More shit.

















​We apologise for the continued delay. Your call is still held in a queue. Please have your reference number ready for the advisor. Your call will be answered as soon as possible.






#4 OFFLINE   Junkman

Junkman

    Totally and properly Renault R16!

  • Full Members
  • 42,609 posts
  • 51 thanks
  • LocationStockport, England
  • Country : Country Flag

Posted 15 April 2018 - 06:22 PM

You got an afm on it? If so, check it's sweeping correctly and within its operating parameters. 8)


A fucking what???
  • BoggyMires likes this

1967 Renault 16 GL............................................now with floor and MoT

1979 Mobylette AV89............................................................running
1997 Peugeot 405 2.0 Executive Estate.................now with aircon and brakes


#5 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    He's a right bastard.

  • Full Members
  • 7,673 posts
  • 37 thanks
  • LocationSheffield On Thames.
  • Country : Country Flag

Posted 15 April 2018 - 06:23 PM

Airflow meter. The metal things with the hinged flap before plastic hot film MAF's.


MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1994 M 318Ti - Track whore

1998 S 323iA Touring. More shit.

















​We apologise for the continued delay. Your call is still held in a queue. Please have your reference number ready for the advisor. Your call will be answered as soon as possible.






#6 OFFLINE   carlo

carlo

    Rank: Renault 16

  • Full Members
  • 2,161 posts
  • 1 thanks
  • LocationPlymouth
  • Country : Country Flag

Posted 15 April 2018 - 06:23 PM

Is an afm a mass air flow meter?  And no I don't know if it has one!  Probably too old.



#7 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    He's a right bastard.

  • Full Members
  • 7,673 posts
  • 37 thanks
  • LocationSheffield On Thames.
  • Country : Country Flag

Posted 15 April 2018 - 06:26 PM

Air flow meter (AFM) - metal and has a hinged flap. As used on Bosch L Jetronic as well as older Motronic. The act of air entering the engine opens the plat and the potentiometer on the flap tells the ECU how much fuel to inject. 205GTi's had these.



MAF - Mass Air Flow. This is a heated element in a plastic tube and the air flowing over it tells the ECU how much fuel to inject.


MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1994 M 318Ti - Track whore

1998 S 323iA Touring. More shit.

















​We apologise for the continued delay. Your call is still held in a queue. Please have your reference number ready for the advisor. Your call will be answered as soon as possible.






#8 OFFLINE   BoggyMires

BoggyMires

    Rank: Austin Maxi

  • Full Members
  • 353 posts
  • 8 thanks
  • LocationThe A14
  • Country : Country Flag

Posted 15 April 2018 - 06:48 PM

Yes. When they wear out they will skip over the potentiometer track at any point causing misinformation to the ECU, either sporadic or no information which will make the engine run like a bag of shite at any given range. Often it will give symptoms of other sensors like the coolant sensor having failed so one can end up changing every part of the injection system without rectifying the issue.

A simple reading test on an ohm meter can show if it's operating correctly, there is lots of information on the web and afm's were used by lots of manufacturers, wear can be adjusted out sometimes too.

Really need to get to grips with testing the injection system and its characteristics first though as it will be expensive changing out random parts. It's not as hard as it makes out.


  • djimbob likes this

1986 BMW 635CSi - Works but doesn't work

1998 BMW E36 318i Touring - Works

2001 Land Rover Discovery V8 - FuBarred


#9 OFFLINE   2MB

2MB

    Rank: BL Wedge

  • Full Members
  • 672 posts
  • 1 thanks
  • Locationup north
  • Country : Country Flag

Posted 15 April 2018 - 06:53 PM

Only petrol Pug I had had a carb so I can’t be of any help but it’s a lovely looking thing and looks well worth sorting

#10 OFFLINE   willswitchengage

willswitchengage

    Rank: Renault 16

  • Full Members
  • 3,279 posts
  • 1 thanks
  • Country : Country Flag

Posted 15 April 2018 - 06:58 PM

Is there 50p stuck in the handbrake?


  • The Reverend Bluejeans, The Moog, Magnificent Rustbucket and 4 others like this



#11 OFFLINE   Jim Bell

Jim Bell

    Rank: £400

  • Full Members
  • 10,379 posts
  • 23 thanks
  • LocationNext door
  • Country : Country Flag

Posted 15 April 2018 - 10:12 PM

Is there 50p stuck in the handbrake?


Hooray!

Its been so long.
  • The Moog, Magnificent Rustbucket, Junkman and 1 other like this
Posted Image

#12 OFFLINE   robinmasters

robinmasters

    Rank: Citroen Ami

  • Full Members
  • 1,894 posts
  • 6 thanks
  • Country : Country Flag

Posted 15 April 2018 - 10:20 PM

Is there 50p stuck in the handbrake?


Looks like there might be one shorting the front fog light wiring.
I used to have a signature, but now I don't.

#13 OFFLINE   carlo

carlo

    Rank: Renault 16

  • Full Members
  • 2,161 posts
  • 1 thanks
  • LocationPlymouth
  • Country : Country Flag

Posted 22 April 2018 - 07:54 PM

Hurrah!!



After a week of faffing around and getting nowhere, and more disillusioned, looks like I might have cracked it.  Simply disconnecting the battery, which presumably resets the ECU, seems to have done the trick.  Idles perfectly, no cutting out and no surging after a half an hour's drive this evening.  Fingers crossed eh  -  had horrible visions of having to but something more modern.





  • The Reverend Bluejeans and RobT like this
