Yugoslavian Ami.., continuing on from 'now-autoshites-flimsy-bodied Shitroen'


  • Please log in to reply
533 replies to this topic

#1 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 01 March 2016 - 12:39 AM

And so it begins..



The day started well, it was a nice and sunny 29th February morning here in Suffolk, but then the post arrived.  Excellent… Sunbeam Owners Fellowship (club) magazine and also one from the 2cvGB club.  The former struggles to fill 14 pages, so the text and pictures are big.  One of the first things I read was news of a friend who's died :-(  A man who had a motorcycle accident 11 years ago which resulted in upper spinal damage.  The thing about him was that he was an optimist and a doer. Wheelchair or not he wanted a Sunbeam outfit, in which he could ride the bike from a specially built sidecar. !  John I'll always remember you mate.. You were an ace.



The 2cvGB club magazine has a new editor and is a more interesting read for me recently, my having in November spotted a Citroen Ami for sale in Slovenia (used to be part of Yugoslavia for those who don't know that corner of Europe).  But more of that in a moment.  4th page in said magazine and I read of someone who's take offence to an article I wrote the previous month.   Sunshine of my day seems to be dimming somewhat.!



Otherwise I got yet another letter from the DVLA regarding a project bike I sold in July and have since been trying to either get a replacement logbook or an age-related number.  D.V.L.A. - funny but rather offensive words come to mind when I un-abbreviate these last two letters.  Perhaps you can help me, what do you reckon does L.A. stands for !?



..it's turning overcast in my dining room.

.. their telephone isn't being answered, so two emails and three scans later I can get on with my day.



midday..



Yo ho ho..,  I'm packing :?  ..to goes on holiday :-)   ..to Slovenia :-D   ..to start recommissioning work on my new Citroen 'Ami- Super Berline'.  :D  Those of you who have been following jonny69's excellent thread on now-autoshites-flimsy-bodied Shitroen might have seem my asking questions.. and a picture of a distinctly shabby, Terry Wogan beige (God bless his cotton socks) pile of .. Shitroen. That's mine.



42 years old, it's been standing for 16+ years.  The same night it was first advertised (on French and German classic car websites)  I spotted it.  I was looking for a 2cv without the rust of British examples, at a price I could afford.. (that didn't happen :-( )



I drove a 2cv to Vienna way back when, in '81 or '82,  but at that time was more into open top lightweight Citroen based kit-cars rather than saloons. I built a Lomax, and then a series of Falcons (different models). The latter I took down to the 2CV world meeting in Portugal and the following year (or was it the preceding year ? ..who knows) down to the beer festival in Munich..  Anyway, years later I moved abroad to work and forgot all about Citroens.



But now ..in my more mature years - I want a simple car, with no power this or that, no servos, no radiator cooling system, no A/c,  in fact not even wind up windows. Bottom line ...not much more than an umbrella on four wheels.  I want to drive the car anywhere I like, round Britain, round Europe, and most likely around Russia too 8)   I want a car I can fix myself without garage facilities, an engine hoist, or a computer.



And the 2cv or Dyane is as simple as one can get.  But, the bloody things have become a fashion accessory for those who would like to be trendy but honestly have no idea ..they follow like sheep. So the cars have become ridiculously expensive to buy now (for what you don't get). I think I paid £50 for the car I drove to Vienna and back in, before re-bodying it as a kit car.



Thankfully there are still a good number of real individuals (like dollywobbler on this and other sites) who actually use their cars, have fun in them, and occasionally even drive them like they're indestructible. :mrgreen:  ..probably would be too if it wasn't for their predisposition to rust from the inside out.



Anyway, I couldn't find anything worth buying within my limited budget and so I started looking abroad.  Spotted a 2cv seemingly relatively rust free in the south of France, but bailed out because of the logistics (no French, no contacts in that part of the world, no trailer, and no towing vehicle).



Then came along this Ami Super. These cars are essentially an Ami-8 on a beefed-up chassis and suspension, with the engine, gearbox and front brakes of the Citroen GS 1015cc. 60% more power than an Ami-8, so they go pretty well (comparable to the early Mini Coopers)..  Story goes that Citroen (after considerable investment) found the 1015cc engine was underpowered for the GS (ostensibly a saloon car with a pretty aerodynamic body).  It made sense for their / the French fiscal rating, &/or for sitting on the Autoroute at high speed (90+ mph for a 1970's 1000cc isn't bad !), but in comparison to its competition - even within France, it sadly lacked low speed pulling power when filled with family, goat, luggage, and a cask of wine. Peugeot were literally pulling away.



Citroen were forced to re-tool the crank and its cases - to increased the motor's stroke. The 1220cc and 1130cc models were born.  Then, Citroen used up the stock of 1015cc motors in the lighter-weight Ami-Super. When those engines ran out - production of this model ended. (45,000 cars from early 1973 to the beginning of 1976).  With everything beefed up the weight saving was just 85kg less than the GS (..and about the same more than the Ami-8 602cc), but the nature of the Ami-super is not that of a motorway burner, nor family mule.. It's a car you drive, it's an engine that loves to spin, and surprising to most - with its low c.of g. the stiffer suspension and chassis work very well too.



Bonus for me is that I'm tall ..and unwittingly growing broader. The Ami is wider inside than the 2cv or Dyane and has high window eye-lines..  Early cars had sliding side windows (front and rear doors), but by 1974 the fronts had been given wind ups :-(   NB, the prior owner of my car might have a pair of doors with siding windows in his store. If so he'll let me have them. Watch this space.



So, having spotted this Ami-8-super for sale I immediately fired off an email to my dear friend Jani, who is Slovenian ...to have him go have a look at it for me.  The following day I telephoned him, pushing him to phone the seller immediately (as I gather the Germans and Dutch are keen on this model).  His doing so bought me some time - as the seller was an honorable chap who wouldn't otherwise sell it until we had first viewed.  Jani knows bugger all about cars, and also happens to be a paraplegic, so he took a friend along to check it out.  'Scruffy as hell but seemingly quite solid' was the opinion.  I ask him to put a deposit on it then and there, but he wouldn't. He insisted I see the car for myself first. So mid last-November I got on an Easyjet flight to do so.  Scruffy, even ugly as sin ..in an interesting sort of way, but reasonably solid.  Not as good as I thought from the photos, so I wasn't sure. Again it was a matter of logistics. A car a thousand miles from home, not running, a welded patch across the foot wells (but unknown under that), and the car so tightly squeezed into the back of a long double garage that I couldn't get around it to inspect.  We asked the seller to hold it for a couple of days while I thought about it..



Ami Super Berline 01.jpg

Autoshite or what !



Prior to the Ami I had been checking out repair panels for the 2cv. Over in the north of Slovenia was a company called 2cvKeza who both make panels and restore cars.  Jani and I made an appointment to visit, and liked what we saw.  Labour rate was a little less than here in the UK and the GBP:Euro exchange rate was good.  Encouraged by the prospect of having the floors professional repaired and the mechanicals recommissioned before driving 1000 miles home, I decided to go ahead and buy the Ami.



We went back the following day and I parted with my savings. I've still only ever seen it half buried under garage / household junk, unable to move, and with stuff piled on it's roof, underneath and inside the car. Tight against a wall on one side, motorcycles packed to within mm behind - I bought the car.  Big risk.   (N.B. the photo above was taken by Jani after I was back in England, when the car was moved)



The plan was to have 2cvKeza do their stuff in April. And then in May or June I'd go back and drive it to England.  Ok so I've not really seen the car yet,  can’t remember ever having driven one, didn't know jack about the motor, nor much else about what was different from the 2cv's (which I last owned 30 years ago).



I flew home the following afternoon, anxiously excited ...just another of Autoshite's certified !?   I still wonder if I'm a damn fool  ( I can hear my dearly departed father say those words loud and clear).  What do they say "He who dares" ..usually get's shafted.!




1 ltr - 54bhp flat 4-cylinder air-cooled ohc motor with low down c.of g. ..in the engine bay somewhere !


So, I've spend the past three months looking for information, advice, answers, workshop manuals, and parts that I suspect I'll need (for a car that's obviously been used & abused, and then left standing for 16 years).  I had a price from 2cvkeza and was shocked (not in a happy way), so the realisation came that I needed to get my butt in gear and to do as much of the work myself, before handing the car over to Janez (2cvKeza) to do the floors and mechanical bits that I don't have the special tools for.



March is here (or is that hare ?) already..


A couple of weeks ago, I managed to cajole Jani's children and future son-in-law to go down to the car (it's still in Koper, on the Adriatic coast - where the car was originally built by Citroen-CIMOS and to squirt penetrating oil on every nut & bolt, screw and fastening they could see. They crawled under,, inside and all around doing this for me, had lunch, and then did it again. I'll do the same on the first day I get to see the car.



I was seriously considering driving down in my old Chrysler Voyager ..to be used as a mobile workshop.., but then realised that I'd first need to buy another tyre ..and snow chains.  Added to this the cost of 2000 mile return trip, ferry & vignettes, 4 days travel at a time when it would probably be too cold to sleep in the car  ..and I thought not.



I then looked into travel by train. Euro-tunnel to Paris, overnight sleeper to Turin, and across to Trieste ..where Jani would pick me up.  Unlike flying - the weight of tools & spare parts would be limited only to what I can drag behind me, across platforms. Then I spotted a link to a company called Luggage-Mule.



In short, this company arrange your luggage to be collected from your home and to be shipped ahead. And then collected and returned to your home after your holiday.  Looking into it..,  I found that I could box up 30kg of parts and tools and have them sent to Slovenia & thereafter returned for £75 plus £20 for £500 of insurance (though I later found a discount code* for 10% off).  A revised plan was hatched : Ship the parts & tools in advance with me following by Easyjet (£150 plus £63 to park for 18 days).  Fly out on 13 March.. oh bollocks I need to get all the parts in mucho-pronto because the advanced shipping is 9 days in advance of departure.  So I read on their website.

* Luggage Mule 10% discount code : trythemule



Today (Monday 29th Feb), most of the part's I've ordered have arrived.  And I'd internet booked with Luggage-Mule on Sunday.  At 2pm this afternoon I get a call from said company to say that advanced collection is 9 working days, so my luggage ought to have been collected today !  It'll have to be tomorrow then.  But I have a hospital appointment / procedure tomorrow at 2:30..  Well the luggage will have to be collected in the morning then..  But, but, but.., some of my tools are on the other side of town.!?  Sorry 9 'working' days.



Off I hastily shuffle to collect my grinder, hammer drill, and cordless screwdriver. Thereafter it's been an afternoon of frantic packing and weighing.. 41kg shit !  Think hard what can I do without ? Remove said items, reweigh... repeat several times..  Merde.. the box is too tall. Max height is 300mm ! This box must be Imperial.  I don't want to get into a penalties, so I repack yet again into two smaller boxes, then tape them together.  The reinforced tape I've ordered hasn't arrived yet.. oh joy of joys.  Print the address labels out and tape them securely on..  Finally.......,  it's done.



I'll have to borrow a ½" drive socket-set from Jani when I get there.. I'm sure his father must have some. And as I couldn't otherwise get the weight all the way down to 30kg - then I'll just have to carry my spanners and smaller sockets in my suitcase on the plane.  In the meantime my home now looks like a tornado has been through.



12.35am on the 1st March ..it's time for bed. ^_^



Bfg.



  • KruJoe, fotorabia, anonymous user and 22 others like this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#2 OFFLINE   colc

colc

    Rank: Renault 16

  • Full Members
  • 3,523 posts
  • 1 thanks
  • LocationZummerzet
  • Country : Country Flag

Posted 01 March 2016 - 09:30 AM

WCPGW?
  • Skizzer and Bfg like this
You can tune a piano, but you can't tuna fish

#3 OFFLINE   Nyphur

Nyphur

    Rank: Renault 16

  • Full Members
  • 2,400 posts
  • 10 thanks
  • Country : Country Flag

Posted 01 March 2016 - 09:52 AM

I'm very much looking forward to this :D Good luck.


LAST OWNER WAS SON OF A BANKER



If it ain't broke, don't fix it. And if it is broke just ignore it, and maybe it'll be sort of OK...?


#4 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 01 March 2016 - 09:54 AM

WCPGW?  you mean like the exchange rate or something ?  :shock:



GBP-EUR-90-day-exchange-rate-history to 27th Mar 16.png



Anyone got Euros they're willing to sell cheap ???





p.s.

Just had a call from the courier to say that they cannot collect this morning.. it'll have to be in the afternoon.   Hang on.. I have a hospital appointment at 2:30, but  should be back by 4pm..   No go, can you leave it 'somewhere safe'.



Leaving it somwhere safe was not an option when I asked..  but now it's convenient to them - it's OK !?


 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#5 OFFLINE   the judge

the judge

    Rank: BL Wedge

  • Full Members
  • 908 posts
  • 0 thanks
  • LocationLiverpool
  • Country : Country Flag

Posted 01 March 2016 - 11:43 AM

Yes!!! More of these shenanigans please!!

#6 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    I blame Thatcher

  • Full Members
  • 5,827 posts
  • 14 thanks
  • LocationOn the shitter reading Practical Classics
  • Country : Country Flag

Posted 01 March 2016 - 11:51 AM

I've just had eight days in France, didn't see a single Ami. The Ami 6 was remarkably ugly as well, saw millions in the seventies.


Autoshite. It's like Pistonheads...but without the wankers.







MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1999 S  E36 318i Touring. Daily shitter.

1994 M 318Ti - Track whore
















#7 OFFLINE   For Fiats Sake

For Fiats Sake

    Rank: Citroen Ami

  • Full Members
  • 1,283 posts
  • 1 thanks
  • LocationHalifax
  • Country : Country Flag

Posted 01 March 2016 - 03:47 PM

1971_Citroen_Ami_8_For_Sale_Front_resize





  • Vince70, laser wheels and Bfg like this

#8 OFFLINE   cort1977

cort1977

    Rank: Citroen Ami

  • Full Members
  • 1,100 posts
  • 9 thanks
  • LocationHouston, TX
  • Country : Country Flag

Posted 01 March 2016 - 04:48 PM

I thoroughly approve of both the style and content of this post.   Bonne chance!


  • tooSavvy and Bfg like this

1974 Pontiac Grand Ville Convertible - The Exxon Valdez

1970 Ford Cortina Estate - In a shed in Ireland




#9 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    I blame Thatcher

  • Full Members
  • 5,827 posts
  • 14 thanks
  • LocationOn the shitter reading Practical Classics
  • Country : Country Flag

Posted 01 March 2016 - 04:54 PM

I see your Ami 8 stunna and raise you:

Attached Images

  • Citroën_Ami_6.jpg

  • chaseracer, anonymous user, dollywobbler and 4 others like this

Autoshite. It's like Pistonheads...but without the wankers.







MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1999 S  E36 318i Touring. Daily shitter.

1994 M 318Ti - Track whore
















#10 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 01 March 2016 - 05:30 PM

Pete, what's 2cvKeza are going to be doing? If the shell is being lifted off for bulkhead replacement, that's a good opportunity for you to do things like remove the suspension arms, regrease the big bearings and replace the old felt seals. Best thing Janez can do is to rust-proof the thing as best he knows how, he should be able to do a better job of that than almost any owner, the trick is to convince him to do so or it could rot again before the running gear is bedded in.



These are simple and hugely tough cars bar corroding bodies, don't get caught in the trap of thinking you've got to treat it like an old English crock and start dismantling lots of stuff - change the oils and filters, grease the kingpins, do the rear brake pipes while the body's off if needed (shoes and cylinders at the back would make sense, too) then drive it hard!


  • Bfg likes this

#11 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 01 March 2016 - 06:42 PM

How can you say that the Ami 6 (as per The Reverend BlueJeans' photo) is ugly :shock:  perhaps it was in the 1970's but surely today - it's a characterful  classic.  :-D



For those who can tolerate opinionated dribble ;  a few months ago I wrote a piece for the club's magazine.  It's an unashamedly slanted Design Engineer's point of view.  ie.,  a brief interpretation of the vehicle's design.





 Citroën Ami Super (1973-1976)



At the time of writing (Nov 2015) there are just sixteen Citroen Ami-Super registered with the UK's  DVLA. These include cars on SORN, and both Ami-Super 'Berline' (saloon / sedan) & the 'Break' (estate / station wagon) bodied cars. And then there's just one Ami-Super Service (commercial variant).  Whatever happened to the thousands that were made ?



There are probably a few more barn-finds as yet unregistered on the DVLA's computer system, and perhaps other still registered as a 'Sidewinder', kit-car, &/or other special... cars which have been built upon the Ami-super chassis.  But the truth is that most of these inexpensive and somewhat eccentric French cars have simply rusted away  'beyond economic repair'.



Some 44,000 Ami-supers were made in the short ; Jan 1973 - Sept '76 model lifespan *  ..now 40+ years ago.  My own car was built in, and also recently bought from the Yugoslavian (now Slovenia) coastal town of  Koper.



* numbers and dates vary according to source.  Cats-Citroen.com for example is generally a good resource for 'all things Citroen' ..but my own car's chassis number is not even in the same Alpha-numerical format as those reported in their production figures.  I suspect this is because my car is a Cimos-Citroen (Yugoslavian) Ami-super which weren't accurately recorded in Citroen's official figures.  The Ami super was possibly also built in Belgium., but are those production figures also included in Citroen's figures.   Likewise the Ami-8 was also built in Spain & Argentina,  but I don't know if the Ami-super was.  I'm not sure anyone is now around who can answer these points for certain, one way or another.



Like almost any other Ami's now being registered in the UK my car is LHD.  They mainly come in from France, Belgium, Holland, &/or the former Yugoslavian countries.  I have read, though cannot confirm, that only one of the UK's 16 Ami-Super survivors is an original RHD.  I have no record of how many retain their original 1015cc horizontally opposed (flat) four-cylinder OHC motor (one OHC per pair of cylinders), as it's tempting to up-rate the car with the GS's more powerful 1220 or 1300cc engine. Either way, these cars are now a pretty rare sight.



I'm an newcomer to this model (purchased recently and not yet registered in the UK). Although I did build a Falcon XS on this platform some 30+ years ago (yes, it still exists), I long ago flew the nest and so am no expert.  However there are plenty of websites which, if one cares to translate, gives us an insight into the car's lineage.  As an born-again A-series enthusiast I've recently done a lot of translating and reading, and so can now share the essence of what is out there..


Background History :



The Ami 6 was introduced in April 1961 as  a model variant of the A-series Citroens.  'A-series' being the economy range / basic-trim spec.,  founded upon the humble Citroen 2cv of 1939 (prototypes) and 1948 onwards (production models).



Like several British car makers of the pre & post war era who adopted the English tax classification as model names for their cars... Austin 7,  Morris 8,  Rover 10, and so on..,  the name '2cv' was simply the French abbreviation of that country's fiscal hp rating. 'Deux Chevaux Vapeur' translates as 'two steam horses'.



A + mi = Ami  = Citroen's A-mid series. The Ami was building upon the A-series' chassis, suspension, engine & drive-train configuration, with its lowest fiscal tax rating.  It was conceived to sit mid-range (milieu de gamme) in the market place, somewhere between the A-series and their family sized saloons.  Of course the name 'Ami' also translates to English speaking countries as 'friend ' ..which is rather nice.

The original Ami 6 Berline (pronounced 'Berlin' and meaning saloon or sedan) is well represented on a number of owner-enthusiast websites. And it's history & specs are available on others, so I'll refrain from repeating those. But rather - from my own perspective as a
(retired) Design-Engineer I'll simply share a few of the car's more interesting features.



Ami 6



To those unfamiliar with the lightweight, small to mid-sized Ami - the early ones (the Ami 6's) are most easily recognised by its unusual deeply concave bonnet (as if scooped out between the headlamps). The forward edge of the bonnet rolls over the grille and the wings carrying this 'roll' diagonally back to the front wheel arch (all-in-all not dissimilar to a bulldog puppy's cute wrinkles :) .. Altogether with wide headlamps, grille, bumper & sidelights - some of these cars seem to wear a most determined frown.!  Fortunately, the car's side aspect with raked-back windows appear quite perky in comparison.



The body sides are also quite distinct - with their having no rear-wheel-arch cut-outs, nor even removable wheel-arch spats ('fender skirts' in American).  And then the Ami-6 Berline also profiled a raked-back rear window, quite similar to the British Ford Anglia 105E  (introduced in 1958).  A similar reverse-raked window style was used in America prior to these Europeans.  Apparently the first appeared in 1953 as a concept / show car : the American 'Packard Balboa-X'.  This was followed by the 1957 Mercury Turnpike, and the Lincoln Continental of 1958.  In the U.S., the style became known as a 'Breezeway Window' - as they opened for additional through ventilation.



On Citroen's little Ami 4 seater ; the reversed rear window design was to facilitate a longer flatter roof line - providing shade for its rear-seat passengers (no sun beating down on the back of their necks) as well as much improved headroom (no window against the back of heads). Internally, the visually length of the headlining was better too, while externally the rear window was out of the rain.  As significantly - because the boot-lid hinges moved forward ; the style enabled an unusually deep top-opening to the luggage-space (..for such a compact car).



The lack of rear wheel arches and the scalloped bonnet are interesting, in-so-much as these were are a practical application of vehicle aerodynamics.  As such it was a break from the 2cv and Dyane models, each with their non-integral wings (mudguards) and slab flat windscreens.. I'm told the early Ami's aerodynamics are 'a notable improvement' over its siblings.



I gather the Ami's headlamps might have been very much lower still, had it not been for the decisive objection of French bureaucrats.  And so Citroen innovated.. the headlamps were market-leading (for the time) ..in so much as their top & bottoms were chopped off .!   ie. they were rectangular - which in turn helped lower the height of surrounding bodywork.

       Four small round headlamps were instead used for some markets such as the USA which didn't accept rectangular headlamps for a number of years yet.



Of course, the 2cv has headlamps mounted on stalks, and the Dyane's were mounted into the bolt-on wings / wheel-arches.  Conversely, the Ami's were mounted into the front grille surround panel.  As was Citroen's usual practice - they also have adjusters (cabled to under the dashboard) to manually adjust / lower the headlamp angle - for when the back of the car was laden.



The 2cv and Dyane's bonnet line each come down to the front bumper and incorporate their grille. Open the bonnet and the front of the engine is accessible to do the points (very low down at the front of the engine, behind the fan).   However, the Ami's front panel is a simple bolt-on affair, which when removed not only gives excellent frontal access to the engine - but also allows better access around either side.  With this panel lifted off ; the Ami's engine can be removed without disturbing the front wings, or without having to lift the engine sky high.  One or two men can easily lift these engines w/ gearbox out without block & tackle.



The low bonnet line was possible because there's no water-cooling radiator on an air-cooled engine. But still.. for any car with the engine positioned forward of the axle - it was an extraordinary achievement. The engine is the flat-twin air-cooled OHV unit (shared with the 2cv and Dyane).., with aluminium engine cases and cyl. heads,  and finned cast-iron barrels.  A crankshaft mounted fan pushes air through ducting fitted around the cylinders.  The same (warmed) air is then ducted / used to heat the car's interior.  With very high oil pressures and a simple balanced design, these engines are as close to being unburstable as anything out there.



The Ami's windscreen too is very different from it's A-series siblings insomuch as it's not only curved but also raked to quite an angle. It's surprisingly deep (top to bottom) for such a small 'economy' car ..particularly so as glass is both heavier & very much more expensive than steel.  The design was enhanced by the design of roof - which follows a horizontal-line theme around the car.  Most other car's roof-lines dip either side across the front, and likewise along their sides, but the Ami has an all-round rain gutter and thereafter a rather flat roof.  With comparable ground clearances (quite generous on these Citroens) I'm led to believe the Ami-6's overall height was 1485mm verses the 2cv @ 1600, and the Dyane @ 1540mm.



And yet, it's as if the designers sought to encourage airflow to go around the windscreen rather than over the top.  I don't know but..,  possibly this was to minimise aerodynamic lift for purposes of vehicle stability (particularly useful with Citroen's compliant suspension), &/or perhaps it was because the all-around gutter allowed the roof to be made in aluminium and be easily attached.?  That of course offers a useful weight saving and also lowered the car's c of g.  Furthermore, the softer metal has advantages of lower tooling cost, which is particularly expensive on the larger body-panel pressings (NB. the 2cv and Dyane saved this cost by each using a canvas roof.)



Did I read somewhere that the Ami-6's (sliding) side door windows were at one time made in plastic to further save weight ?



Either way, the windscreen is up tight under this flat-roof's gutter - which give a good (high) eye-line.  And, as practiced on most early Citroens - the windscreen & door pillars are commendably slim (visibility unhindered) - even by today's standards.  The results are most noticed from within - Ami's are unusually light & airy inside.



Below the window line ; the Ami's body sides are rather bulged, and then feature a slightly recessed almost flat panel - from just forward of the front door posts to the car's rear lights, and then the bottoms of the side panels tuck under. With no rear wheel arches to interrupt this line - it's quite a futuristic styling statement - in an Art-Deco sort of way.  The relief also serves to lessen the throw of the door hinges and (like a corrugation) helps to stiffen the door skins  ..Yet another advanced design idea that is now commonplace.



Nowadays, manufacturers would fill such doors with electric motors, side-protection beams, and monster speakers, but in 1961 the bulged door skins, when combined with the sliding (forward & back door) windows were simply fitted with useful door pockets ..2cv owners don't know what they're missing !



In 1964 ; the Ami-6  'Break' (a remarkably spacious 'little estate' version) was introduced, with folding rear bench seat and an almost flat (albeit sloping-down forward) rear floor.  The spare wheel (both for the Berline & Break models) is housed under the bonnet.  A 25 ltr (400km range) fuel tank sits low-down between the chassis's rear outrigger legs.  And being a front-wheel-drive (with no prop shaft nor rear differential), with independent rear suspension - this model offers a very useful load volume indeed.  It then also has a lifting tailgate, and a usefully low sill / load height ..not bad for the early-1960's !



Today, the Ami may at first glance look odd and from some angles even angular, but in fact its body lines are very much cleaner than it's siblings or most competitors. Combined with a lower frontal area and rounded windscreen - these applications of aerodynamic ideas result in it being able to sustain higher cruising speeds more easily and more economically.



..to understand the car further - it's perhaps best to see it in its period context ..in this stylish Ami-6 promotional film

< here >



Chassis & Suspension :



It's worth adding that the A-series cars (the 2cv, Dyane, and Ami, each with a van derivative)  has a pressed-steel 'punt' style chassis about 5" deep,  is narrow (about half the width of the car),  the full length of the vehicle (extending from front to rear bumper mount), and upswept at each end for better ground clearance. Although the chassis has internal webbing and cross beams - its top & bottom skins are flat.  The top skin is the floor within the car, and the bottom one is of course aerodynamically smooth. 8)



With all round independent suspension since the first 2cv's in 1948 ; each corner utilises a swinging arm. These are made from steel, are hollow and shaped like a curved horn.  Tubes are intrinsically very stiff for their weight, and these taper from large diameter bearings at the chassis end, to being compact at the wheel end - thereby minimising the suspension's unsprung weight.  Their long length and ease of rotation, together with 'compliant' spring rates all greatly contribute to lessening the twisting forces on the chassis.  And because of this - the chassis can be lighter in weight ..it is after all a lightweight car with a small engine.



Mounted to either side of the chassis - the suspension springs are laid horizontal / in-line with the chassis, so again there's next to no twisting.  Likewise the exhaust pipe & its silencer box is run alongside the chassis, so nothing hangs down below the chassis level.  The front brakes of these cars are inboard, mounted to the sides of the gearbox/differential, with ducting from the fan to keep them cool.  Rear brakes are drums, more or less contained within the 15" deeply pressed steel wheels.



A-series suspension.jpg



Anti-dive Suspension geometry when braking Along with a designed low c of g.,  the suspension arm's long length and axle position / axis of rotation (being closer to mid-ship) - each work well to prevent nose diving ..

         in brief  :  If you draw a line between the axle's chassis mounting point and the (braked) front tyre's contact patch (straight line in red, diagram above) - you'll see the angle (in side view) is somewhat less than 45 degrees.  Because of this low angle - the car settles rather like a dog screeching to a halt on it's haunches.!   Even more so as weight bears on the front axle (ie. the effect is greater the harder you brake) because this angle becomes even less.



In stark contrast ; regular front wishbone suspension reacts around its almost vertical geometry (again, the line between the axle's chassis mounting and its road/tyre contact point)  ...is like tripping over upright front legs.!



During braking, the forward inertia of any car is tripping over the braked-tyre's contact with the road.  The torque reaction is 'around' the point of road grip (counter clockwise / LH red arrow in the diagram above)., and the only thing stopping the axle from flipping forward is the suspension arm's connection to the chassis.  Because of the length & angle of the Citroen's suspension arms.. this counter-clockwise force (in the diagram above) tends to gently lift the front of the Citroen's chassis ..thereby contributing to balance out the natural tendency to dive.  It's all very clever in its remarkable geometric simplicity !



In addition.., because the rear suspension arms are attached to the chassis forward of their tyre contact points - the torque reaction (similarly counter clockwise in the diagram above) acts to push down on the axle-chassis mountings,  ie., the rear of the car ! (RH curved red arrow).  As suggested ; the A-series suspension is geometrically designed to drop on haunches rather than to pitch nose down.  It was deliberate and essential for cars with soft suspension  ..And it works amazing well.



Additionally., a simple swinging-arm tube with a few brackets welded on is far more economical to produce than the numerous parts (with spindles and bushes) of front wishbones and chassis suspension towers.  And then, because the Citroen's swinging arm geometry minimises both bending and shear forces - it can be made still lighter in weight.  And by way of a bonus ; it has a better ground clearance than most lower-wishbone configurations (..less likely to snag when used around a farm-yard or to drag through mud or snow).



Similarly at the rear - the swinging arm design is a fraction of the weight, size, or complexity of cart-leaf springs, mounting points, Panhard rod, and live-axle configurations - commonly used on 'other' cars of the period (..and for many years thereafter !).



With sealed oversized axle bearings (which never seems to wear) the regular maintenance point of the Citroen's suspension configuration is just the four connection link-pins ..between the spring's tie-rods & each arm.   Overall, although I have to admit those arms do look humorously gangly / ungainly - it really is a compact and brilliant design.



Thrown into a corner 'a little too fast' - any car with long travel and compliant suspension will roll..  but in truth - it looks very much more dramatic to onlookers than it feels to the occupants.  Naturally, this is 'played upon' for effect,  but it's also worth remembering that these cars were designed for the family man - facing the harsh reality of post-war Europe .. and not for what we now call 'boy-racers'.  Accordingly, that very same suspension is unparalleled  for comfort and  handling within its economy class..



Around corners the car heels but you have to try very hard indeed to lift an inside wheel.  Accordingly tyre contact is maintained ...as is traction,  steering,  and braking.  Overall it is simple, elegant (in an organic insect sort of way), and yet brilliant in principle and execution.



The Citroen's steering is by rack and pinion, which is housed within the front axle cross tube.  Its interesting that this was possible on an economy post-war car ..when marques such as Jaguar still used a steering box - right the way through to the XJ6. !?





The Ami-8



The Ami-6 was popular in the French marketplace but sales in other markets were not good.  The Berline looked just too different and then had a small engine and very soft suspension - which the traditional British and German markets equated to ; seriously lacking power and unsure handling.  It also competed with the 2cv & then the Dyane (introduced in 1967) which likewise offered excellent accommodation for its size.



And so, along came the Ami 8  Berline / saloon, with its long fastback style / sloping forward rear window (again providing good shade and headroom for rear seat passengers).  Launched at the Geneva Motor Show in March 1969, and otherwise retaining many of the early car's attributes, while lessening its eccentric styling.  The new model's bonnet line was less extremely scalloped between the headlamps, and it's now recessed opening was moved back to a more 'normal' position' behind the front panel.  The bonnet's rolled edge across the front and down to the wheel-arches was gone.  And the stylised décor around the side lights and on the front wing sides were smoothed out.



At the rear ; the wings were squared off a little with rear-light units now set into these.  This move enabled the boot lid to be opened from the rear rather than top face of the luggage space. Those familiar with the GS will recognise the big square load space, complete with very low sill.  Like the Ami-6, the Ami-8 (and Super) frees up useful luggage space by stowing the spare wheel under the bonnet.



Aside from the frontal clean-up in style, the Break / estate version of the Ami 8 had a similar appearance to the Ami 6, although the rear lights were likewise moved and set into the rear wings, which again lowered the tail-gate loading height / sill to rear-bumper-level and a more level floor within.  The 2cv & Dyane have a step in the floor over the petrol tank, which extends outwards as clearance for the suspension arms. In contrast, the Ami had a much lesser step height, and shallow pressings in the floor to give clearance for the suspension arms.



In September 1969, the Ami 8 became the first A-series to be fitted with inboard front disc brakes. And after 1970 the front-door's sliding windows gave way to wind-up windows …and no door pockets.



With it's slightly longer and broader body,  a little more complexity and stiffness in body panels, plus extra luxury in trim and glass (in comparison with it's lithe siblings) - comes additional weight.  I understand therefore that the suspension's spring rating was stiffened up and an anti-roll bar fitted between the front suspension's swinging arms.  In addition, the later Ami-6 and then Ami-8's had slightly more powerful versions of the 602cc flat-twin motor.



The Ami not only became more agreeable to the eyes of foreign markets of the 1970's  but it's aerodynamics were further enhanced.  The Ami's redesign is attributed to the French car design & bodywork company - Heuliez.




The Citroen's GS



Aerodynamically acclaimed ; Citroen's GS  was introduced in August 1970, with a horizontally opposed flat-four OHC air-cooled 1015cc engine.  The engine capacity was deliberately small to be within the French fiscal ratings.  Of course in this day n' age it's more relevant to insurance premiums.  On paper, it was a super (no pun intended) motor..  Flat-four's are inherently smoother than in-line 4-cylinder configurations.  And then they are both more compact (lengthwise) and have a very low c of g.  The GS motor has aluminium crank cases & cylinder heads - which equate to less mass and more easily controlled vehicle-handling characteristics.



Belt driven OHC  (overhead camshaft) engines are also quieter and smoother (having tighter tolerances and less reciprocating mass) than push-rod engines.  And then again - short stroke engines are smoother and generally rev very well - to achieve admirable peak BHP power figures. The 1015cc GS motor with 55bhp has 74mm bore x 59mm stroke, and so it's well 'under-square'.  Short stroke engines have lower piston velocities than long stroke (for the same rpm)..  and therefore wear and stresses are less.  Compression ratio is on this engine is 9:1 and the concave piston crowns with hemispherical heads are of an advanced design.



However great these characteristics may be for high engine speeds.., any short stroke engine has less torque (pulling power) than an otherwise similarly spec'd long-stroke engine of the same capacity.   At 893kg  the 1015cc Citroen GS  was of course a heavier car than any of the A-series, and it had a great load volume /  capacity (laden weight of 1312 kg).  Add then engine-driven hydraulic pumps to power its suspension ...and the car's usable pulling power was somewhat lacking.



Whereas short strokes may be great for a high speed lightweight sports car - they are far from ideal for the family estate / mule.  Needing to be driven through-the-gears, those 'revs' are contrary to the fuel economy expectations of the family orientated consumer.  That said - the 1015cc GS was car of the year in five European magazines for 1972 and so must have been an exceptional driver's car for the press ;)  Unfortunately, for the family man it simply lacked the grunt or economy of its competitors.  Citroen were forced into building a new engine with more torque, and that meant an increase in the engine's stroke.



Lengthening the engine's stroke meant a physically bigger crankshaft & cases..,  and longer barrels.   But still the French were enslaved to how their fiscal ratings effected car sales …they had to keep the capacity down.  Ironically the last variant of the GS engine was made for the Italian market ..whose own restrictions meant that no car under 1300cc was allowed on their motorways.  Citroen took the GS's bore out a little to 1301cc - just for that market.

Of course Citroen had invested a great deal into this all new 1015cc engine's design, its tooling, and production-numbers purchasing / stock pile of component parts.   Many of those were to be 'used up' in the Ami-Super.





The Ami Super (1973 - 1976)



The concept was simple enough. Take the compact / lightweight but still eminently useful and comfortable Ami-8  ..and shoehorn the GS 1015cc flat-four engine into it  (Some say that this had already been done with an Ami - built as a test mule for the new engine).  The Ami-8 at 725kg  is 20% lighter in the weight than even the basic spec GS, and it doesn't have the load volume / carrying capacity.



In that one simple step Citroen's market for the compact mid-range was extended.  Those markets who wanted more than 602cc flat-twin motor were answered ...and Citroen had its own boy-racer model !  Of course it's fiscal rating shot up from 3cv to 6cv,  but with the Ami-8 still in the range - it did give the customer in France &/or abroad a interesting choice …economy or performance.



The 2cv and Dyane models and variants were probably not deemed rigid enough to take the power ..as indeed the standard Ami-8 wasn't !   No, the chassis of the Ami-super was not only modified to take the flat-four engine, with its under-slung exhaust manifolds, but it was stiffened too. Ostensibly the Ami-8 chassis is made from 0.8mm gauge steel, whereas the Ami Super's went up to 1.2mm thick.



It's simple math's to work out that this alone added 50%  to the chassis weight.  Possibly some body panels were similarly beefed up.  And then the fuel tank grew to 40 litres.  Add to this the additional weight of a four cylinder motor - and it's clear the car needed more powerful brakes, front and rear.  Albeit with an Ami-Super specific bell housing - the gearbox and front brakes are those of the 1220cc GS.  And the rear brakes are slightly larger drums than the Ami-8.  It's a small step thereafter to see that the suspension also needed up-rating with stiffer springs.  An anti-roll-bar was added to the rear suspension arms too.



There are a host of more minor beefing-up differences between the Ami-8 and the Ami-Super - with a resultant gain of  85kg (unladen weight).  In the big picture that's an additional 12% more than the Ami-8 ..but it's still  83kg / 10%  less than the 1015cc engined GS.   The saving grace was that most of the extra weight was low down in the chassis,  suspension, and flat-4 boxer engine / drive-train components…  And that's all very positive with regard to its c.of g. and the Ami-Super's handling.  In the meantime - the car's engine power increase was 62% more than the Ami-8  (..approximately x3 more than the original Ami-6). :shock:



The advanced suspension of the GS was either deemed too expensive for the compact saloon  &/or for marketing reasons - the gap between the Ami-Super and the GS's spec's needed to be more clearly defined. So although beefed-up, the 'super' benefits from the simplicity in chassis, suspension and steering design of its sibling A-series.  The engine is much the same as that used and proven in the GS., but without hydraulic take-offs.  The super is said to be rated at 53.5 BHP,  which is 1.5 BHP less than the GS  ..Most likely, this is down to exhaust pipe differences ..and as much marketing hype as fact.


Interesting perhaps to 2cv and Dyane owners., who might anxiously think of all that engine weight hanging out the front of the car - is that the Ami-super's engine is in fact cantilevered from its gearbox mounts. The Ami-super's chassis front-cross-member has no engine mounts at all.  So although the car's dynamic c.of g. is further forward than the twin cylinder models ..the static / normal speeds contribution to longitudinal c.of g. is some 15" further back than might first be envisaged.  In short, its not nearly as bad as you might think !



In the meantime, the GS got it's new engine at 1220cc with 77mm bore and 65.5mm stroke.  It's compression ratio was reduced from 9:1 to 8.2:1.  Together with cam changes the result was 60 BHP @ 5750 RPM -v- 55 BHP @ 6000 RPM for the 1015cc.  However torque went up by almost 24% to 64.3 ft.lb @ 3250 verses  51.9 ft.lb @ 3500 RPM.  A very useful increase !   In performance terms the difference was unnoticed in either top end speed or economy (30.4 mpg DIN),  but the 0 - 50mph acceleration times dropped from 12.3 to 10.6 seconds.  Bottom line was the engine became more tractable and easier to drive, most especially when laden.  Probably for fiscal (tax) rating reasons - the 1015cc engine remained in the catalogue for the GS range.






... The Ami Super however retains anonymity on the road.  There were significant differences under the skin but few showed through.  Six small air-intake slots were tucked in under the  grille to aid cooling and induction. There's also differences in front bumper brackets, but aside from that and 135 section tyres - just a few stick-on badges differentiate the Ami-Super from the Ami-8.   Pierced wheels were added in '74 and waistline graphics came through in 1975.




How well does the Ami-Super work ?



" As might be expected from the specification, the effects of these changes on the performance are little short of startling. The 0 to 60 mph acceleration time, for example, is nearly half that of the regular Ami-8  and a fraction quicker even than the GS saloon with 1015cc motor.



Top speed is up 16 mph over the Ami-8,  to a mean 88 mph. And we reached over 90 mph with the aid of a slight tail wind. On the grossly optimistic speedometer we once saw an indicated 100 mph, equivalent in truth to 92 mph. Considering how the Ami body makes little pretence at streamlining it is all the more remarkable that top-speed of this Super version should be only 2 mph behind that of the more aerodynamic GS



At the kerbside,  the Ami Super weighs about 150lb more than the Ami 8 and is about the same amount less than the GS.  For a test mileage of 654 very hard miles, in which we enjoyed the performance to the full and regularly revved to over 7,000 rpm, the consumption was 27.4 mpg.   This is 4 mpg better than that of the GS and about 5 mpg worse than that of the Ami 8.   With the kind of restraint that comes with longer acquaintance (although we doubt novelty will ever wear off completely), owners should easily return 30 mpg or better. Our test car, by the way, was delivered to us with less than 1,000 miles behind it and so performance and consumption should both improve with longer running in.



All these facts and figures tell a vital part of the Ami Super story, but they do nothing to describe the unique way the car behaves in traffic on the road. As you turn the starter and the engine comes slowly to life it sounds a lot like the old air-cooled twin.  At the bottom end it has something of the familiar sluggish response. But from about 3,500 rpm it is almost as if two extra cylinders have switched in somehow, and the car takes a great leap forward as the revs scream up to around 8,000 rpm. Taken to this limit, where the urge cuts out suddenly, over 30 mph is possible in bottom, nearly 60 mph in second and just short of 80 mph in third.



The torque curve in fact is much flatter than it feels and the car's low speed pulling power is remarkably good. Big 15in. dia. wheels prevent any traction problems and although the Super rolls a lot - like all Ami's - it feels stiffer than the smaller-engined version.  Brakes are extremely powerful and well up to the task of coping with all the extra speed.



There has been nothing quite like this Citroen since the original Mini-Cooper, and for £995 including tax it is very good value."

Autocar Brief Test - 21 June 1973



Interior wise,  the Super has a 160km/hr speedo and a floor mounted gear change. And the handbrake lever is inverted, but those things aside - it's much the same as an Ami-8.  It is a compact car and as such it has just 2" more shoulder width than the 2cv6 (front & rear).  The car has winding front door windows, with sliding windows and storage bins for the rear seat passengers.



With its spare wheel mounted under the bonnet, the Berline's boot space is a very usable rear loading 'box' of almost 12 cu.ft.  By way of comparison the 2cv has (almost) 9 cu.ft. and whose space is less convenient.   Personally, I'd prefer a 5th door / lifting tailgate, and removable parcel shelf like the GS, which would add to the usability of the luggage space quite considerably.   The Berline's rear seats are quickly removable, whereas the 'Break' has a tailgate and a folding &/or removable rear seat - for the additional luggage carrying capacity.



Of course in most senses - the Ami-Super is as useful and practical as any Ami-8.  The body shells are likewise as 'Berline', 'Break' and 'Service' models,  and have very similar 'Luxe',  'Confort' or 'Club' trim specifications, including differences in headlining.  My own car was probably built as a Luxe with a bench front seat, but that has been changed to non-reclining individual seats from a 1972 'Confort'  Ami-8   (the 'Club' having reclining front seats).





That concludes this report for now.   In my view - each & every Citroen has its own virtues and also its quirks.  The Ami-Super is no different.  It's panel fit is appalling,  and the very thin-gauge body panels and crude interior trim may be nice and lightweight, but they also reek of 'economy'.   I appreciate that this car doesn't appeal to most,  but still I hope something in the above has been interesting and informative to all enthusiasts.



As said from the outset - I'm no expert in this or any other Citroen model.  My purpose was only to share an overview.  Please excuse if I've made an error or two (dozen).!  I'm sure there are owners and garage experts who might like to write in with a snippet, or correction.  Perhaps even a tale or two from direct experience.?



Best regards,  Peter.,  in Suffolk.


Acknowledgements & thanks to the excellent Citroenet website for the adverts. More to see and read < here >



NB. the above text has been appended to ..to include a discourse on the A-series chassis and suspension. 12th March 2016


  • anonymous user, forddeliveryboy, hauserplenty and 4 others like this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#12 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 01 March 2016 - 07:00 PM

"Pete, what's 2cvKeza are going to be doing?"



Thankyou, I stand corrected 2cvKeza rather than as I had typed 2cvKaza.



Presently I have asked 2cvKeza to give me a price for :

1.  replacing the front footwell floors & lower bulkhead (with authentic to original panels), examining and replacing as required the box section.

2. to examine the rest of the body and advise what else needs welded repair.

3. with the body lifted off ... to clean and repaint the underside of the body and also the chassis.

4. to recommission (check, clean out old grease and replenish with new)  all the A-series mechanicals - the suspension, wheel bearings, rear brakes, and steering.

5. to repaint & then refit the fuel tank (which is presently out of the car).



In short, to do what's needed to repair and protect the metalwork.  And also to get the car fit for inspection, and the 1,000 mile pan-European trek home.



Painting underside and chassis will be in 2-pack primer and then rubberised stone chip.  I've specified this in light-grey as I hate black undersides on my cars.   All box sections and closed in areas are to be wax oiled (drilling appropriate / additional access points as required).



I can't afford him to do much more so I'll do anything else myself  :  GS mechanicals and front brakes,  all top-side panels,  plus the wiring,  fuel and ignition, and ancillaries,  plus the glazing,  lighting,  interior,  seatbelts, locks & latches ...each as required.

Hence the desire to have all my tools and 'garage stuff' with me as a mobile workshop.



It'sa  going to be interesting.  As the man says - WCPGW !?


  • Skizzer and Sigmund Fraud like this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#13 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 02 March 2016 - 09:29 AM

Like a dog with an itch that can't quite be reached.. I'm going to look at a 2cv for sale ..today :rolleyes:





"oh dear Peter, how many times do I have to tell myself.. 'no more than two projects at once'.."



Oh shit, I'm talking to myself again  :boomer:


  • privatewire likes this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#14 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 02 March 2016 - 04:24 PM

4. to recommission (check, clean out old grease and replenish with new)  all the A-series mechanicals - the suspension, wheel bearings, rear brakes, and steering.





There's not much to do with A-series running gear, it's all quite 'sealed for life' for its 1940s origins, except the kingpins and sprung TREs.



Rear brakes will need new cylinders and shoes. Easy.

Suspension pots will need oiling - easy. 10 mins. Knife edges, a little oil/grease. 5 mins. Could be quickly and easily removed for cleaning/checking when the body is off. Perhaps an hour's work.

Steering - not possible to regrease where needed until the rack is apart, leave as is if it's unworn - should be at that mileage.

   Outer steering balljoints - check and if necessary replace the rubber boots, grease the joints if all looks dry.

Kingpins - grease.



If you're driving it back to the UK, check the footbrake pads have plenty on them and perhaps work the pistons back and forth a few times. Make sure the handbrake is adjusted for the inevitable stop on a mountain pass.



#15 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    I blame Thatcher

  • Full Members
  • 5,827 posts
  • 14 thanks
  • LocationOn the shitter reading Practical Classics
  • Country : Country Flag

Posted 02 March 2016 - 04:26 PM

The Ami 6 is so ugly, it's impossible to dislike. I love 'em.


  • anonymous user and Bfg like this

Autoshite. It's like Pistonheads...but without the wankers.







MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1999 S  E36 318i Touring. Daily shitter.

1994 M 318Ti - Track whore
















#16 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 02 March 2016 - 05:15 PM

I find the 8s as attractive as the 6s weren't. But they never look as good on pics as in the flesh. Super-streamlined for their time, even if they don't look it. Flywheels as heavy as a Barratt house seem to impart extra speed. My 8 would do a satnav 88 on the level, many more on gentle motorway inclines, but it had been round the clock. I think most rotted before the engines had done enough miles to give their best.



Then there was a friend's 'Dyane' on a Super chassis - that was quick, not a lot could keep up on A and B roads.


  • Bfg likes this

#17 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 02 March 2016 - 08:09 PM

"There's not much to do with A-series running gear, it's all quite 'sealed for life' for its 1940s origins, what then about 40+ year old, dried-out grease in wheel bearings ?  ..except the kingpins and sprung TREs.  what is/are TREs ?



Rear brakes will need new cylinders and shoes. Easy.  yep, I've bought new cylinders and shoes.



Suspension pots will need oiling - easy. 10 mins. Janez will do this when the body's off but out of interest - how does one oil inside closed tin cans.?  Is it squirted in where the tie rods come out  ?  Knife edges, a little oil/grease. 5 mins. I'm surprised there's no kind of rubber boot over these.  Could be quickly and easily removed for cleaning/checking when the body is off. Perhaps an hour's work.  I can live with that ;-)



Steering - not possible to regrease where needed until the rack is apart, leave as is if it's unworn - should be at that mileage. I couldn't investigate while the car was tight in the back of the seller's garage (the only time I've seen it) but there's 30 degrees of play at the steering wheel !?   There's also a spare steering wheel (with better condition rim) in the car,  so I'm optimistically hoping that the steering column is not tightened up, or the UJs in the column are shot (rather than the rack).  I base this only on not expecting both outer steering ball-joints being near equally worn to that extent.



Outer steering balljoints - check and if necessary replace the rubber boots, grease the joints if all looks dry.



Kingpins - grease yes, as you kindly advised ; I'll warm first and then grease.



If you're driving it back to the UK, check the footbrake pads have plenty on them and perhaps work the pistons back and forth a few times. I've bought new calipers and brake pads - in case required.   Also a new compensator valve.   I'm hoping the master cylinder is OK because I couldn't identify which one it was, so haven't even got a repair kit for that.   I'll have Janez replace any brake pipes that he has any boubts about.



Make sure the handbrake is adjusted for the inevitable stop on a mountain pass. Wise man !  Thanks


 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#18 OFFLINE   The Reverend Bluejeans

The Reverend Bluejeans

    I blame Thatcher

  • Full Members
  • 5,827 posts
  • 14 thanks
  • LocationOn the shitter reading Practical Classics
  • Country : Country Flag

Posted 02 March 2016 - 08:33 PM

I find the 8s as attractive as the 6s weren't. But they never look as good on pics as in the flesh. Super-streamlined for their time, even if they don't look it.



.....But then, Citroen built what is probably the prettiest small saloon of it's era, a title it must share with the steel bumper Alfasud.



Behold.

Attached Images

  • 4410570citro_25C3_25ABn-gs-sp_25C3_25A9cial-06.jpg

  • chaseracer, anonymous user, Lacquer Peel and 2 others like this

Autoshite. It's like Pistonheads...but without the wankers.







MASTER RACE MOTORS.



1989 F  730i. Prestigious.

1999 S  E36 318i Touring. Daily shitter.

1994 M 318Ti - Track whore
















#19 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 02 March 2016 - 08:47 PM

Like a dog with an itch that can't quite be reached.. I'm going to look at a 2cv for sale ..today :rolleyes:



Two and half hours drive either way (A140 through Norwich aargh !!) :







2cv Dolly in Celeste blue.  137k miles but mechanically well maintained.   One genuine lady owner from new  ..so complete history.  Has an after-market galvanised replacement chassis (15 years ago). And its  MOT'd to Nov 16.

..but also numerous patches welded around inner body shell,  inc. cills + grp patches in several places

+ some sprayed-over filler (unknown quality of repair under these).



To me,  for a daily driver - a localised patch or two is fine to keep a car roadworthy.  But when at  some point these panels have so many patches - they ought to be replaced.  imo,  this car's sills,  rear inner arches,  c-post lowers,  are all due for replacing. Possibly ; the floors. lower bulkhead with reinforcement brace too and boot floor too.  Then also..,  the body, wings and front bumper are starting to fray with rust.

All do-able but not value for me, not least at this time.  :-(


 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#20 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 02 March 2016 - 09:37 PM

"There's not much to do with A-series running gear, it's all quite 'sealed for life' for its 1940s origins, what then about 40+ year old, dried-out grease in wheel bearings ?  ..except the kingpins and sprung TREs.  what is/are TREs ?





Track rod ends. Don't be tempted to tighten them to remove play, replace the drop arm since the ball will be badly worn. Highly unlikely unless someone without any knowledge has meddled. Worth picking up a pair in Slovenia if they're available.



Wheel bearings rarely dry out unless the seal's gone, in which case the bearing will be knackered. It's possible to introduce more grease between the two races if there's sufficient gap, this means driveshaft and hub carrier removal.



Before setting off home, I'd spend a day or two and a hundred miles in the vicinity of 2cvKeza so teething problems can be sorted out. You can't guarantee a 40 year old machine to be hauled out of a barn and hit the road without something cropping up, even with an expert's eye cast over it and repairs done where needed.



Has the car got the correct slotted wheel rims? - they're stronger, as required by a car which is so much heavier at the front.


  • Bfg likes this

#21 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 02 March 2016 - 10:33 PM

TREs - thanks. ;-)



Will again discuss with Janez re. wheel bearings.  I hope he'll be doing them as I don't have those tools yet.



Yes, I'll certainly be doing a few hundred miles in his vicinity before using the car long distance, especially as Slovenia is an Alpine country.  It's through Austria if I head directly north-west, or 2 days through the Dolomites and then into Switzerland if I come back through Italy.  I've driven both. The latter on a motorcycle was fantastic riding,  so I'd much prefer to bring the super back through those mountain roads.  :D   If so, then the engine's revs, it's gearbox, brakes and every aspect of the car's quick handling will be put through its paces - so it'll need to be right.



Bloody Marvelous :happydance:





Alas, only the spare out of the five wheels are slotted.  Repro's available new from Germany at around about 45-50-euros each, but I can't keep spending.  If I happen upon a used set of steel-slotted from the GS at the right price then I might be tempted,  but all the tyres are perished - which is a lot more demanding of any 200-euros I might have.


 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#22 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 03 March 2016 - 01:57 PM

Team Squirt - Slovenia..  I'd asked Jani to press-gang his probable future son-in-law (Jan) and two children(Larisa and Matej) into going around all the nuts, bolts, screws, fastenings and anything else that might looks as if it dismantles - to squirt with penetrating oil in anticipation of it thing having to come apart / body off..   Here's just a few photos of their work a couple of weeks ago :




Team Squirt either having a turn or break dancing ?




Under bonnet with the spare removed, showing the famed Shitroen wiring & cable runs

    ..and their fetishism for tubes  :D




Surely the ugliest dashboard ever shat ? with it vast array of instrument, and an economy in steering wheel spoke. while the lime green nylon seat covers did nothing for car's sales  north of Brentwood.   Q. How is that the French, who are world-acclaimed in the arts and fashion, were so incredibly crap at styling, colour and material selection for their 1970's car interiors.  ??    I have no idea what the red-LED box screwed to the side of the instrument does ..doubtful if original to 1974 Yugoslavia - perhaps it's the Nitros-oxide boost !?




A prerequisite for Citroen : The seats are quickly lifted out for picnicing.   The photo reveals the welded plate(s) across the foot wells.  In stark contrast, this car's rear floors are clean and straight.



ditto below





the wine cavern's not in too bad shape, but for a short strip of grp either side - to keep the water out (or in ?). White over-spray makes it look worse ..you see - the car was loved once upon a time.!  Ah.., I've just realised that this space is actually the speaker enclosure / back box.! :shock:



The starburst is actually the elastic of the back seat. This bench also simply lifts out - room for the family goat ..rather than the kids.!  Alternatively, lift the seats out and lay your sleeping mat down. <_<






Down under, showing chassis mounted horizontal suspension spring (in can) and damper, connecting to the underside links of the RH swinging arm, squirted !!  The sill, side-body-outriggers, and jacking points look to be in good shape.  Bottom of the rear door skin has minor rust staining (quite unlike a few British cars of the era).




no, not trying to fly away, simply airing..  Who mentioned skinny wheels ?

  763 views


  • anonymous user, Lacquer Peel, Vince70 and 2 others like this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#23 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 04 March 2016 - 11:06 AM

My car's parts & tools - sent in advance via LuggageMule,  were collected on Tuesday 1st pm - and have now arrived at my friend Jani's house in Slovenia,  midday 4th March :



I'm very glad..  But why then was it such a rush for me to pack & wrap them 13 days in advance of my arrival date (on the 13th)  !!! ??? :roll:


  • privatewire likes this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#24 OFFLINE   stuboy

stuboy

    Rank: Renault 16

  • Full Members
  • 3,269 posts
  • 6 thanks
  • Locationashford kent

Posted 04 March 2016 - 06:16 PM

looks like a fun drive back to blighty


END of the road for the  MONTURDO !! :-(  :-(  :-(

Long live fozzie the Focus  :wub:  :wub:  :wub:


#25 OFFLINE   Tamworthbay

Tamworthbay

    Rank: Renault 16

  • Full Members
  • 4,671 posts
  • 11 thanks
  • Country : Country Flag

Posted 04 March 2016 - 06:20 PM

Two and half hours drive either way (A140 through Norwich aargh !!) :




2cv Dolly in Celeste blue.  137k miles but mechanically well maintained.   One genuine lady owner from new  ..so complete history.  Has an after-market galvanised replacement chassis (15 years ago). And its  MOT'd to Nov 16.

..but also numerous patches welded around inner body shell,  inc. cills + grp patches in several places

+ some sprayed-over filler (unknown quality of repair under these).


To me,  for a daily driver - a localised patch or two is fine to keep a car roadworthy.  But when at  some point these panels have so many patches - they ought to be replaced.  imo,  this car's sills,  rear inner arches,  c-post lowers,  and boot floor are all due for replacing. Possibly the floors and lower bulkhead with reinforcement brace too.  Then also..,  the body, wings and front bumper are starting to fray with rust.

All do-able but not value for me, not least at this time.  :-(

How much were they asking?

#26 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 04 March 2016 - 06:32 PM

£1500 as advertised in the 2cvGB club magazine.  But I'm sure it'll be gone this weekend.  It wasn't so bad if one was able and willing to do the welding yourself.  And at this time - I just can't take on another project.  I'm too firkn old,  and already have projects* lined up around my head and up my jacksie.  :shock:



If I were to have someone do it..  then it would have cost a £-couple-thousand for the welding, wheel-bearing / kingpin, and a set of wheels, etc.    So, £3500 for a 2cv that then needs a paint job and has 137,000 miles - is not what I considered good value.   Seen on this 'ere website are much better cars for £-hundreds not thousands (albeit they're not 2cv's).



My owning a 2cv is a genuine hankering for a simpler way of life ..not to be a dolly owner





Tamworthbay - noting your avatar re. punk rock bands..

     * one of the other projects I'm half way through is my 1953 Sunbeam-S7  once owned by Martin 'Youth' Glover - bass player in Killing Joke  -  aka 'Orion'.  He went on to be a successful music Producer < https://en.wikipedia...i/Martin_Glover > .  Prior to this (pun intended) the bike was owned by 'celebrity photographer' Mr Mike Prior - London.., who using the bike in his  studio as prop for unknowns like - The Nelson Twins (sons of Ricky) and the book cover of 'A Bit More Fry & Laurie' :






     This same bike was first registered in London on the first day after the HM The Queen's Coronation.  But whether the unusal silver colouring is a direct consequence of this - I can only speculate ...but it may be that the London Motorcycle dealership celebrated the occasion in style 8)





...well,  that veered a little off- thread di'n't it ! ?


  • ShiteRider likes this

 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#27 OFFLINE   Chris2cv

Chris2cv

    Rank: Austin Maxi

  • Full Members
  • 119 posts
  • 0 thanks
  • LocationLondon
  • Country : Country Flag

Posted 04 March 2016 - 07:46 PM

I love old Citroens, and have a 2cv. I read this with interest, and wish you the best of luck. Wish I had the nerve to do something like this!


(The 2cv is)" a vehicle with almost every virtue, except speed, silence and good looks"  The Motor 30th December 1953







Current fleet : 1985 Citroen 2cv6 Special - (Greased Lightning)

                       2002 Renault Clio

                       2010 Peugeot Vclic (moped)



 Now here - 2017 Dacia Sandero Stepway Laureate!




#28 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 05 March 2016 - 02:23 PM

"Simpler way of life ...not to be a dolly owner" - couldn't agree more. But I'd say an Ami dash is a thing of beauty, minimalistic elegance. Those pics weren't the best at showing it in its best light!



Seem to remember you reckon the single spoke wheel is for cheapness - it became a Citroën thing because in the fifties, rather than have a steering column pointing at your chest, ready to spike through it in a head-on collision, they continued the column and bent it over and round so there was no pointy bit facing you. Only 2cvs and Dyanes omitted this, even if they had a single spoke wheel.





citroen-ami-8-interior.jpg?w=610&h=457





  • anonymous user, Skizzer, Vince70 and 1 other like this

#29 OFFLINE   Bfg

Bfg

    Rank: Citroen Ami

  • Full Members
  • 1,009 posts
  • 7 thanks
  • LocationWesterfield, Suffolk, England, UK
  • Country : Country Flag

Posted 05 March 2016 - 03:26 PM

oooowh..  is that what it's meant to look like ! ?  ..mind you the earlier Ami-6 is still very much neater to my eyes..   But then I think the old Austin Mini's central speedo with parcel shelf either side and its massive door pockets was just superb ;)



8)  "it became a Citroën thing because in the fifties, rather than have a steering column pointing at your chest, ready to spike through it in a head-on collision, they continued the column and bent it over and round so there was no pointy bit facing you."

I do like this sort of tidbit..  It's utterly brilliant !  :mrgreen:



I wonder, over the decades - how many such clever design solutions (from all sorts of industries)  have already been forgotten, or not even universally known about in the first place.!?    fdb - I think a new thread is called for .. on just that sort of design solution - excellent ..


 ...its a bloody motor car  ..not a Fabergé egg. !

.

< Here > is a link to my former Sunbeam S7 / S8 motorcycle restoration business website.

And the story of my buying & now restoring a  1974 Yugoslavian Ami-Super  is < Here >

.


#30 OFFLINE   forddeliveryboy

forddeliveryboy

    Rank: Citroën Ghia

  • Full Members
  • 7,577 posts
  • 6 thanks
  • LocationEurope
  • Country : Country Flag

Posted 06 March 2016 - 02:02 PM

There's so much intelligent design on old Citroëns it would bore everyone stupid on here, probably more suitable for a one-marque forum (although even there, when I last dared peek, lots of what was once common knowledge seemed to be forgotten or not understood).



Those cynical of the 2cv and its ilk's abilities best look away. People today generally don't get intelligent design, more it's a matter of making something bulky and screwing as many airbags inside and relying on 'intelligent' electronic systems to protect you - I'm not knocking them, just that some think until Volvo started banging on about safety nobody gave it a thought.



Just as a taster, even the cheapest little-est Cit had its fuel tank placed between the rear wheels, protected by several feet of chassis as well as the massive back axle tube. The chassis at the front had a break point which was designed to give in a big impact, stacking the engine and box vertically and preventing them being pushed through into the cabin. Once an impact reaches the suspension arms, the car gets pushed clear, so no further intrusion (unless you're crushed between two Land Rovers). Moreover, the steering assembly was at the back of the engine bay, bolted inside the front axle tube. Although it's a lethal non-collapsing column, it's difficult for it to move very far into the car. All this was dreamt up before, during and just after WW2 and was used on a car meant as one step up from a horse and cart.



The guy responsible for the 2cv, DS and H-van was killed road-testing a DS mule in a Traction Avant shell at high speed, I wonder if it was the steering column which did for him, it does sit close to the driver and the rack was a fair way forwards with the Traction (and DS). Hence the attention to the column, turning it round and forming the rim of the steering wheel?


  • loserone, Skizzer, mat_the_cat and 2 others like this




0 user(s) are reading this topic

0 members, 0 guests, 0 anonymous users
